Model Number: ERD20 and ERD21
INSULATED ROLL UP FIRE DOOR SYSTEMS
Our Firemiser Insulated Fire door combines the functionality of the rolling fire door with the benefits of an insulated service door.
In the event of a fire, the fire door functionality of this door allows it to save lives and protect property. The fire door works to compartmentalize a building to eliminate the spread of smoke flames, keeping the fire isolated.
The mineral wool used to insulate this door, helps to control sound transmission – featuring an R value of 5.3 and a U Value of .189 based on the ASHRAE Handbook of Fundamentals. The insulation also helps in a climate controlled environment by helping to maintain a different temperature on the interior and exterior of the door.
A Firemiser insulated fire door is perfect for an application that is currently exterior, but there is a planned expansion that will require the opening to be fire rated in the future.
Our insulated rolling fire door is UL listed, Factory Mutual Approved and listed with the California Office of the State Fire Marshall. It is listed with a protection ratings of 45 minutes, 90 minutes, 3 and 4 hours.
Our fire rated insulated rolling doors are also available in model number ERD21 with a SmokeShield® seal package. This optional package controls smoke and drafts while conforming to UL1784. This seal package will ensure that the smoke will also compartmentalized with the flames.
A standard UL labeled door is available up to 13.5’ wide by 12’ high.
An oversized UL labeled door is available up to 60’ wide or 40’ high or 1,200 Sq. Ft.
For openings that are larger than those listed, please contact us.
Materials and Finishes
Firemiser curtains are available in:
Interior slat 24 gauge / Exterior slat 24 gauge
Interior slat 22 gauge / Exterior slat 24 gauge
Interior Slat 20 gauge / Exterior slat 24 gauge
Interior slat 18 gauge / Exterior slat 24 gauge
Interior slat 22 gauge / Exterior slat 22 gauge
Click here for additional material and finishes options and information.
Finish and gauge availabilits and y may vary. Contact us with any questions.
Insulated fire doors can be installed face of wall or between jambs on an interior or exterior wall. Acceptable wall types include masonry, structural steel jambs and drywall construction with structural steel or wood studs.
Check Out How We've Helped These Clients With Custom Closure Solutions:
"We are very pleased with the performance of the Cornell doors. Throughout the area, doors are blown out everywhere and the building we just moved from was destroyed. Here, our $2.3 million of inventory was saved. Being satisfied with the Cornelldoors is an understatement!"
ROGER WEIR, OPERATIONS MANAGER AT LEWIS BEAR COMPANY
"CornellCookson had installed a rolling door for us in our old building. We used it all the time and it’s held up really well over the years. Calling them in again made perfect sense. We are thrilled with how this door looks. The level of detail that’s been captured so clearly on this large door is incredible. It’s exceeded our expectations by far and will definitely do its job as a focal point in our new building."
MARK WORMAN, OWNER OF GRAVEYARD CARZ
"The existing grilles we had installed prior could not stand up to the cycle usage, and they needed a lot of maintenance. Cornell's Extreme Performance 324 grille is the right product, far superior to the other grilles we had in this opening before. We are really happy with the performance and will definitely purchase this product going forward, when the next opportunity arises."
MARK ARGABRIGHT, FACILITY MANAGER AT YOHN PROPERTY MANAGEMENT
"Not only was functionality a major concern, but we also needed a custom closure solution that worked with the overall exterior aesthetic of the building which is rooted in neighborhood context. We collaborated with CornellCookson to develop a solution that is both functional and architecturally sensitive."
EUGENE FLOTTERON, CETRARUDDY ARCHITECTURE
"The SteelWeave Metal Mesh Grille was the perfect solution to meet all of our needs. It complimented the design of the bar and lobby while adding some elegance. We could not be happier with the look and function of our CornellCookson SteelWeave Metal Mesh Grille and custom sliding panel."
DONALD FOX, FOX THEATERS
Smoother Installation and easy maintenance: Designed with a flexible black rubber TPE material, our new sensing edge has two fins that conform to variations in the floor on both the interior and exterior of your door or grille. This ensures a secure seal without requiring you to overset the bottom door limit. The new sensing edge is easy to clean and remains free from rust and dirt stains, maintaining a fresh uniform appearance.
Edges are tested and listed to UL 10B as a component of the rolling steel fire door assembly.
Stronger weather protection: Featuring flexible 1" sealing fins, our sensing edges withstand the elements, providing maximum protection
SmokeShield® Seal Package
Often required by local building codes, our smoke seal adds smoke and draft control.Learn More
Optional safety devices on provide a visual and/or audible advanced warning when the door is about to close .
Battery Back Up Devices
Available for motor, chain and crank operators, these devices prevent fire doors from closing from a power failure.Learn More
Firefly & Firefly BB Release Device
Optional device that ties in to a building alarm system and closes a FireGard fire door upon alarm activation, rather than by melting its fusible link.
Safely and conveniently test and reset the functionality of the fire door at floor level. May be flush or recess mounted.
Omni Powder CoatOmni Powder Coat now allows you to match your rolling steel doors with select Clopay sectional doors to create a unified and refined style.
Omni Powder Coat is available in:
- Commercial Tan
- Commercial Gray
- Standard White
- Chocolate Brown
AtmoShield™ Powder CoatingTextured powder coat finish that combats the environments harsh wear and tear. This finish provides a thicker, more scratch resistant coat for added product protection.
Hood and Operator Covers
Metal cover to protect the coil or operator from exterior weather, debris or to meet OSHA or UL 325 safety requirements.Learn More
SpectraShield™ Powder Coating
Polyester finish in more than 180 colors for durability, aesthetics, superior finish life and cost effectiveness.Learn More
Trim PackageIn applications where exterior aesthetics are important, such as hotels, condominiums, convention centers and parking garages, the addition of a trim package can cover unsightly hardware and contribute to the building's architecture.
High Cycle SpringsHeavy duty springs manufactured to withstand cycles of 100,000.
Seismic Performance Validation
We can provide project specific seismic calculations for all coiling doors that are mounted Face of Wall to steel or masonry. Seismic performance validation is per ASCE 7-05.
Entrapment Protection Devices
Entrapment protection devices ensure that a motorized door or grille will not close on an object. If an object enters path of closure, the entrapment protection device will stop the door or grille from closing and return it to the fully open position.
Guide-Mounted InterlocksAn electrical cutout switch to prevent motor operation if locking device is not first disengaged.
Rolling Door Protector (RDP)
The RDP eliminates costly fork truck damage to coiling doors by creating a physical barrier at the top of the door that absorbs impacts.
Static Wind LoadCan be configured to withstand the full range of specific wind load requirements including missile impact ratings.
Sloping or Irregular OpeningsOur special bottom bar designs can address these conditions.
SmartSync™ Wireless Safety Edge & Wireless Remote Controller
The Smartsync™ Safety Edge Kit is an upgrade for our existing Safety Edge. This allows for wireless communication between the transmitter and the receiver, eliminating the coiling cord in the door opening. Learn more.
The Smartsync™ Wireless Remote comes equipped with an anti-shock design for industrial handling. This heavy-duty remote is compatible with most motor-operated doors, grilles or counter door.*
*Not compatible with NEMA 7/9 operators
