AESTHETIC
Five different curtain
patterns to choose.
CUSTOMIZABLE
Different models, allowing
the versatility to fit any application.
SECURE
316 stainless steel curtain provides
protection while allowing visibility.
Patterns
Lago
Lago features a tight weave for privacy and protection as well as used for sun shading. This weave features an open area of 44%, a minimum visible light transmittance of 0.15 and a maximum visible light transmittance of 0.51.
Tigris
Tigris has a more open weave to let more light in while maintaining security as well as sun shading. This weave features an open area of 64%, a minimum visible light transmittance of 0.47 and a maximum visible light transmittance of 0.67.
Helix 24
A specialty pattern offered that is big on both aesthetics and protection. This pattern features an open area of 56% and provides thicker links in a larger weave. The same type of weave in a smaller style is available in the Helix 48.
Helix 48
A specialty pattern offered with a unique aesthetic for your security grille. This pattern features an open area of 48% and provides a wave look that is eye-catching. The same type of weave in a larger style is available in the Helix 24.
Sambesi
A specialty pattern offered with a thicker, more rigid weave. It can also be used for sun shading. This weave features an open area of 42%, a minimum visible light transmittance of 0.12 and a maximum visible light transmittance of 0.45.
Models
Aesthetic Reveal
The Aesthetic Reveal model is ideal for areas where the entire unit needs to be a work of rolling art. The entire exterior of the grille has no visible fasteners, meaning that the stainless steel perimeter is sleek and inviting. A hood that is unobtrusive and hides the mechanics underneath covers the coil. This model is a great option for tighter spaces where recessing the perimeter is not possible.
Aesthetic Conceal
One of the most popular models for this product is the Aesthetic Conceal. This is where the top and sides of the grille are buried into the wall – leaving the beautiful stainless steel grille and bottom bar front and center as the star of this protective closure. Because this model is recessed, the guides are aluminum and no hood is required, saving on cost while still featuring a stunning woven grille.
Service
This model is both functional and cost-effective. Perfect for areas where a tighter grille pattern is required to maintain airflow while restricting trespassers large and small. While the sides and bottom bar are aluminum and no hood is included, the curtain is still stainless steel.
Security
The SteelWeave Metal Mesh Grille complements and enhances any building design while still providing security. This grille features a durable type 316 stainless steel curtain that provides protection for the people or objects behind the grille while still allowing visibility, even in the most corrosive environments. Optional security features include - locking mechanism, remote monitoring and control via a master panel dependent on the choice of operator.
