Model Number: ESD10
Rolling Security Door
When you need a high-security roll-up door that offers superior protection, you need a roll-up door from Cookson. Our roll-up security doors work 24/7 to defend your building against threats such as unwanted entry, burglary and destructive vandalism. We engineer our rolling doors to protect against inclement weather at both interior and exterior openings in industrial, commercial and institutional buildings.
We weren’t happy with the bulky, outdated roll-up metal security doors of the past — so we created a better, custom-made option. This high-security roll-up door withstands daily use with ease and warrantied for up to 50,000 open and close cycles — more than twice the amount of many competitive brands. This door is fully supported by side guides for maximum clearance in areas with limited overhead space, with hand-crank, push-up and motor operation available.
Each overhead coiling door is custom-built to meet your specific design requirements, resulting in a door that's uniquely yours. With Cookson, you can customize different parts of your door, including:
- Material: Choose a rolling door manufactured from stainless steel, galvanized steel or aluminum.
- Finish: Create a unique look by customizing your finish, including clear anodized, medium or dark bronze anodized, black anodized or mill finish. We also offer SpectraShield™ powder coating, available in more than 180 different colors.
- Slats: Customize your ventilation and visibility with custom slats.
- Graphics: Add durable, full-color vinyl graphics to your rolling security door to display your brand logo, school mascot or business sponsors.
- Windows: Let in some light and increase visibility with one-way and two-way integrated windows.
- Safety features: To get even more out of your rolling security door, opt for additional safety and protection features, like locks, wind load protection and weather seals.
With Cookson, you have an entire design and support team standing by to assist. Contact us today to start building a rolling security door that meets all of your needs.
Standard door curtains are available in:
- Galvanized Steel:
|Slat Gauge||GalvaNex Color|
- #4 type 304 finish
- Minimum 20 gauge
- Mill Finish, Clear anodized, Medium bronze anodized, Dark bronze anodized, Black anodized
*Finish & Gauge vary – contact us for availability or custom design requests.
Daily use? Check. 20 cycles per day? Check. 50,000 lifetime cycles? Check.This door is up to the task.
If you need more or more frequent cycles, or if you want a door that’s speedier, check out our line of High Performance Doors.
- Standard construction: 30’ wide, 30’ high
- Non-standard construction: contact Architectural Design Support
SpectraShield™ Powder Coat Finish
Polyester finish in more than 180 colors for durability, aesthetics, superior finish life and cost effectiveness.Learn More
Chain Diverter for MGH Operators
This option moves the auxiliary chain out of the clear opening and to the side of the door – enabling free movement through the door and making a chain bag unnecessary.
Slats with multiple small window size punched slots that create an open curtain design. Maintains a high level of security while allowing for ventilation and visibility.Learn More
Hood and Operator Covers
Metal cover to protect the coil or operator from exterior weather, debris or to meet OSHA or UL 325 safety requirements.Learn More
Add durable, full-color images to your curtains and hoods. Great for school logos and turning unused door space into profitable sponsorship opportunities in stadiums, amusement parks and retail stores.
Vision WindowsImprove aesthetics and visibility with one- or two-way windows incorporated in the curtain.
Magic SwitchA touchless activation device designed to open and close doors with the wave of a hand. It's compatible with all operators that have a primary entrapment device and are configured for momentary contact to close. The Magic Switch is easy to retrofit in an existing application and features a clean, stainless steel face plate.
High Cycle SpringsHeavy duty springs manufactured to withstand cycles of 100,000.
Seismic Performance Validation
We can provide project specific seismic calculations for all coiling doors that are mounted Face of Wall to steel or masonry. Seismic performance validation is per ASCE 7-05.
Entrapment Protection Devices
Entrapment protection devices ensure that a motorized door or grille will not close on an object. If an object enters path of closure, the entrapment protection device will stop the door or grille from closing and return it to the fully open position.
Guide-Mounted InterlocksAn electrical cutout switch to prevent motor operation if locking device is not first disengaged.
Heavy Duty Bottom Bar
The HDBB is 350% stronger than traditional bottom bars, preventing forklift damage to your Service or Insulated Door. The HDBB can pay for itself after the first impact and significantly reduce future maintenance costs.
A wide variety of locking options are available to meet your security needs.
Quick Repair DoorQuick Repair Doors doors are provided with 3' or 6' of extra curtain, an impactable bottom bar and removable lower guide sections. These features allow for faster repair of slat damage, reducing downtime and maximizing the lifetime value of your door.
Rolling Door Protector (RDP)
The RDP eliminates costly fork truck damage to coiling doors by creating a physical barrier at the top of the door that absorbs impacts.
Weather SealInclude weather seals at the guides and bottom bar with an internal hood baffle at coil housing. Lintel mounted nylon brush seal also available.
Static Wind LoadCan be configured to withstand the full range of specific wind load requirements including missile impact ratings.
Operational Wind LoadCan be configured to withstand an operational wind load of 20 PSF.
Pass DoorsHollow metal man door and hinged frame available within a curtain.
Sloping or Irregular OpeningsOur special bottom bar designs can address these conditions.
Superimposed DoorsCombine two different curtains on the same opening. Typically, an insulated door is used in conjunction with an open design rolling grille to provide ventilation. When extreme weather or sound resistance is desired, we can provide superimposed/double insulated curtain assemblies.
Combine two different slat profiles in the same curtain. Typically, a standard slat is combined with a perforated slat or even rolling grille for ventilation and security.
MullionsThere are multiple mullion options - corner, fixed and removable.
